1220 ADJUSTABLE HINGE

  • Larger non-rise hinge for use on heavier reach-in doors
  • Offsets adjust easily; just loosen mounting screws and reset serrated adjustment plate
  • Round bearing pins for longer life than competitive models
  • Use for right or left- opening door
  • Simple conversion to spring hinge for self-closing applications
  • Interchangeable for right or left opening door
Specifications

MATERIAL

High pressure, die-cast zinc flange and adjustment plate, stainless steel cover, and zinc plated steel strap.

FINISH

Polished chrome.

OFFSETS

See ordering information.

ADJUSTMENT RANGE

3/16" (4.8 mm)

MOUNTING

Drilled and countersunk for No. 10 (5.0 mm) screws.

LOAD RATING

See Hinge Selector Chart, Group B.

PACKAGING

24 each

WEIGHT

Approx. 18 lb. (8.2 kg) per carton.
