1845 HIGH FLOW INTELLI-VENT® HEATED
PRESSURE RELIEF PORT

  • Large flow capacity for warehouse and large walkins
  • Opening/closing pressure reduction increases walk-in’s lifespan
  • Imperial 6-watt heater ports provide 50% more heat to resist frost build-up from humid air entering freezer
  • Thermostatic control protects unit from heating during times when walk-in has no refrigeration
  • Air-Ram nozzles reduce frost accumulation
  • Low-profile, exterior screened hood protects against infestation
  • Accommodates any wall thickness from 3-1/2 inches
  • Easy installation

NOTES:

  • Walk-In operation temp range: -20°F(-28.9°C) to 40°F(4.4°C)
  • Normal capacity: 1 per cf in freezer, 1 per cf in coolers. Use quantity calculator for application details.

U.S. Patent No: 8,992,293

U.S. Trademark: 4,269,018

Specifications

SIZE

Requires opening 11-1/2" H x 17-1/4" W x 3-1/2" D (280 x 432 x 77mm) Min.

MATERIAL

Textured ABS exposed panel and hood.

POWER

120 VAC ,60 Hz, 56W, .50 amp or 220- 240 VAC, 60 Hz, 56W, .25 amp.

UL LISTING

File No. E57306
